1. The input signal is computer analog RGB (VGA)/digital interface (DVI)/high-definition interface HDMI (with audio)/analog CVBS (AV), analog VGA supports input signal amplitude of 0.7Vp-p, supports separate row/field synchronization, composite synchronization, and green synchronization;
2. The resolution of the input signal can support up to 640 * 480 75Hz, 800 * 600 75Hz, 1024 * 768 75Hz, 1280 * 1024 75Hz, 1366 * 768 75Hz, 1680 * 1050 75Hz, 1600 * 1200 75Hz, 1920x1080 60Hz. It can perform large-scale scaling processing on the input signal within the VGA to WUXGA range to achieve optimal display.
3. The input power supply is 12V DC (Min: 9V, Max: 15V), with a current of 2.0A or above (the power consumption of the driver board itself does not exceed 2W in pure display operation, and other power consumption includes sound amplifiers, high-voltage boards, and the backlight of the selected LCD). The selection of power input depends on different screens, and the larger the screen, the greater the power consumption;
4. The driving signal output to the LCD supports single pixel 8-Bit or 6-Bit and dual pixel 8-Bit or 6-Bit LVDS interface TFT LCD and 6-bit TTL interface TFT LCD, with a maximum display color of 16.7 million colors;
5. Plug and play, compliant with VESA DDC1/2B standard;
6. Flexible OSD menu adjustments can be made using a 6-key keypad, including brightness, contrast, phase, clock, image position, position of OSD menu itself, OSD menu language, color temperature, volume, factory reset, and more;
7. Supports most models of 42 inch and below digital TFT LCDs from manufacturers such as AU, LG Philips, Samsung, CPT, Sharp, Chimei, Fujistu, Hannstar, Sanyo, etc. Specific modifications to LCD interface cables and software may be required;
8. Supports external stereo audio input and outputs stereo audio to speakers (supports 2 * 3W-3R).
9. Support controllable 5V fan power output
10. Support human body sensing input, automatically control entering and exiting sleep mode
11. Onboard temperature monitoring function, automatically shuts down when the temperature is too high
12. Supports brightness sensing input and can automatically adjust screen brightness.
